Multiwfn is an extremely powerful program for realizing electronic wavefunction analysis, which is a key ingredient of quantum chemistry. Multiwfn is free, open-source, high-efficient, very user-friendly and flexible, it supports almost all of the most important wavefunction analysis methods. 64 bit Windows, Linux and Mac OS platforms are supported.
Multiwfn is maintained by Tian Lu (卢天) at Beijing Kein Research Center for Natural Sciences (http://www.keinsci.com, 北京科音自然科学研究中心). Multiwfn is always in active development, the original paper is J. Comput. Chem., 33, 580-592 (2012).
Official forum of Multiwfn (in Chinese): http://bbs.keinsci.com/forum.php?mod=forumdisplay&fid=112.
Reporting bug, seeking help or providing suggestion, please contact developer: sobereva[at]sina.com.
- Input files supported by Multiwfn
Multiwfn accepts several kinds of files for loading wavefunction information: .wfn/.wfx (Conventional / Extended PROAIM wavefunction file), .fch (Gaussian formatted check file), .molden (Molden input file), .31~.40 (NBO plot files). Other type of files such as Gaussian output file, .cub file, DMol3 .grd file, .pdb file, .xyz file can be used for specific functions.
- Special points of Multiwfn
- Comprehensive functions. Almost all of the most important wavefunction analysis methods (except for NBO methods) are supported by Multiwfn.
- Very user-friendly. Multiwfn is designed as an interactive program, prompts shown on screen in each step clearly tell users what should do next, Multiwfn also never prints obscure messages, hence there is no barrier even for beginners. In addition, there are about 100 well-written tutorials in the manual, which are very helpful for new users.
- High efficiency. The code of Multiwfn is substantially optimized. Most parts are parallelized by OpenMP technology. For computationally intensive tasks, the efficiency of Multiwfn exceeds analogous programs significantly.
- Results can be visualized directly. A high-level graphical library DISLIN is invoked internally and automatically by Multiwfn for visualizing results, most plotting parameters are controllable in interactive interface. This remarkably simplified wavefunction analysis, especially for studying distribution of real space functions.
- Primary functions of Multiwfn
- Showing molecular structure and viewing orbitals (MO, NBO, natural orbital, etc.).
- Outputting all supported real space functions at a point.
- Outputting real space function in a line and plot it as curve map.
- Outputting real space function in a plane and plot it as graph. Supported graph types include filled-color map, contour map, relief map (with/without projection), gradient map, vector field map.
- Outputting real space function in a spatial scope, data can be exported to Gaussian-type grid file (.cub) and can be visualized as isosurface.
- For the calculation of real space functions in one-, two- and three-dimensions, user can define the operations between the data generated from multiple wavefunction files. Therefore one can calculate and plot such as Fukui function, dual descriptor and density difference very easily. Meanwhile promolecule and deformation properties for all real space functions can be calculated directly.
- Topology analysis for electron density (AIM analysis), Laplacian, ELF/LOL etc. Critical points and gradient paths can be searched and visualized in terms of 3D or plane graph. Interbasin surfaces can be drawn. Values of real space functions can be calculated at critical points or along topology paths.
- Checking and modifying wavefunction. For example print orbital and basis function information, manually set orbital occupation number and type, translate and duplicate system, discard wavefunction information from specified atoms.
- Population analysis. Hirshfeld, VDD, Mulliken, Löwdin, Modified MPA (including three methods: SCPA, Stout & Politzer, Bickelhaupt), Becke, ADCH (Atomic dipole moment corrected Hirshfeld), CHELPG, Merz-Kollmann and AIM methods are supported.
- Orbital composition analysis. Mulliken, Stout & Politzer, SCPA, Hirshfeld, Becke and natural atomic orbital (NAO) methods are supported to obtain orbital composition.
- Bond order analysis. Mayer bond order, multi-center bond order (up to 12-centers), Wiberg bond order in Löwdin orthogonalized basis and Mulliken bond order are supported. Mayer and Mulliken bond order can be decomposed to orbital contributions.
- Plotting Total/Partial/Overlap population density-of-states (TDOS, PDOS, OPDOS), up to 10 fragments can be very flexibly and conveniently defined. Local DOS (LDOS) can also be plotted for a point as curve map or for a line as color-filled map.
- Plotting IR/Raman/UV-Vis/ECD/VCD spectrum. Abundant parameters (broadening function, FWHM, etc.) can be determined by users, individual contribution from each transition to the spectrum can be studied.
- Quantitative analysis of molecular surface. Surface properties such as surface area, enclosed volume, average value and std. of mapped functions can be computed for the whole molecular surface or for local surface; local minima and maxima of mapped functions on the surface can be located. Becke and Hirshfeld surface analysis are also supported.
- Processing grid data (can be loaded from .cub/.grd or generated by Multiwfn). User can perform mathematical operations on grid data, set value in certain range, extract data in specified plane, plot integral curve, etc.
- Adaptive natural density partitioning (AdNDP) analysis. The interface is interactive and the AdNDP orbitals can be visualized directly.
- Analyzing real space functions in fuzzy atomic spaces (defined by Becke or Hirshfeld). Integral of selected real space function in atomic spaces or in overlap regions of atomic spaces, atomic multipole moments, atomic overlap matrix (AOM), localization and delocalization index (DI), condensed linear response kernel, multi-center DI, as well as four aromaticity indices, namely FLU, FLU-pi, PDI and PLR can be computed.
- Charge decomposition analysis (CDA) and extended CDA analysis. Orbital interaction diagram can be plotted. Infinite number of fragments can be defined.
- Basin analysis. Attractors can be located for any real space function, corresponding basins can be generated and visualized at the same time. All real space functions can be integrated in the generated basins. Electric multipole moments, orbital overlap matrix, localization index and delocalization index can be calculated for the basins. Atomic contribution to basin population can be obtained.
- Electron excitation analysis, including: Visualizing and analyzing hole-electron distribution, transition density, transition electric/magnetic dipole moment and charge density difference; analyzing charge-transfer by the method proposed in JCTC,7,2498; plotting transition density matrix as color-filled map; calculating delta_r index to reveal electron excitation mode; calculating transition dipole moments between all excited states.
- Other useful functions or utilities involved in quantum chemistry studies: Weak interaction analysis via RDG method (including fluctuation environment analysis); plotting scatter map for two functions in specific spatial scope; integrating a real space function over the whole space by Becke's multi-center method; evaluating overlap integral between alpha and beta orbitals; evaluating overlap and centroid distance between two orbitals; monitoring SCF convergence process; generating Gaussian input file with initial guess from converged wavefunction or multiple fragment wavefunctions; calculating van der Waals volume; calculating HOMA and Bird aromaticity indices; calculating LOLIPOP index; calculating intermolecular orbital overlap; Yoshizawa's electron transport route analysis; calculating atomic and bond dipole moment in Hilbert space; plotting radial distribution function for real space functions; plotting iso-chemical shielding surface (ICSS); calculating overlap integral between orbitals in two different wavefunctions; parsing output of (hyper)polarizability task of Gaussian; calculating polarizability and 1st/2nd/3rd hyperpolarizability by sum-over-states (SOS) method; outputting various kinds of integrals between orbitals; calculating center; the first and second moments and radius of gyration for a real space function; exporting wavefunction to .molden, .fch and GAMESS-US input file with $VEC; calculating bond polarity index (BPI); evaluating oxidation state and so on.
- Real space functions supported by Multiwfn
Real space function analysis is one of the most powerful feature of Multiwfn, about 100 real space functions are supported and listed below, detailed descriptions can be found in Section 2.6 and 2.7 of the manual:
- Electron density
- Gradient norm of electron density
- Laplacian of electron density
- Value of orbital wavefunction
- Electron spin density
- Hamiltonian kinetic K(r)
- Lagrangian kinetic G(r)
- Electrostatic potential from nuclear / atomic charges
- Electron localization function (ELF) defined by Becke and the one defined by Tsirelson
- Localized orbital locator (LOL) defined by Becke and the one defined by Tsirelson
- Local information entropy
- Electrostatic potential (ESP)
- Reduced density gradient (RDG) with/without promolecular approximation
- Sign(lambda2)*rho (The product of the sign of the second largest eigenvalue of electron density Hessian matrix and electron density) with/without promolecular approximation
- Exchange-correlation density, correlation hole and correlation factor
- Average local ionization energy
- Source function
- Others: Such as potential energy density, electron energy density, shape function, local temperature, bond metallicity, linear response kernel, local electron affinity/electronegativity/hardness, ellipticity of electron density, eta index, on-top pair density, numerous DFT exchange-correlation potential, Weizsäcker potential, Fisher information entropy, Ghosh/Shannon entropy density, integrand of Rényi entropy, steric energy/potential/charge, Pauli potential/force/charge, quantum potential/force/charge, PAEM, density overlap regions indicator (DORI), region of slow electrons (RoSE), PS-FID, single exponential decay detector (SEDD), electron linear momentum density, electric/magnetic dipole moment density.
Implementing a new real space function into Multiwfn is extremely easy, as illustrated in Section 2.7 of the manual.
